System And Components
8N-3309 DRIVE GP-FANS/N 99C3088-UP
Group No: 8N-3309
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N3306 | 1 BRACKET AS-FAN | 1 | |
| 1S9209 | 2 SHAFT-TIGHTENER | 1 | |
| 4N0955 | 3 DOWEL | 1 | |
| 8T9391 | 4 BOLT (1/2-13X3.75-IN) | 2 | |
| 8T4223 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T8919 | 6 BOLT (1/2-13X1.75-IN) | 2 | |
| 2P1757 | 7 HUB-FAN PULLEY | 1 | |
| 8N5305 | 8 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 3L1425 | 9 BALL BEARING | 1 | |
| 8N3305 | 10 ADAPTER-FAN | 1 | |
| 7N1275 | 11 PULLEY-FAN DRIVE | 1 | |
| 5N4751 | 12 V-BELT SET (INCLUDES 3-BELTS)(FAN)(INCLUDES 3 BELTS) | 1 | |
| 7F0938 | 13 BOLT (5/16-24X3.25-IN) | 2 | |
| 7N2900 | 14 RETAINER | 1 | |
| 9F4446 | 15 SEAL-O-RING | 1 | |
| 8T9101 | 16 BOLT (3/8-16X2.75-IN) | 6 | |
| 6V8801 | 17 NUT (3/8-16-THD) | 6 | |
| 8H9789 | 18 BALL BEARING | 1 | |
| 5S2106 | 19 SEAL-LIP TYPE | 1 | |
| 5S9062 | 20 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 9B7237 | 21 BOLT (3/8-16X1.25-IN) | 1 | |
| 8L5008 | 22 ELBOW-PIPE | 1 | |
| 8T4896 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 3B8489 | 24 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 8K4037 | 25 HOSE AS | 1 | |
| 6N4111 | 26 BRACKET AS | 1 |
