System And Components
125-5065 DRIVE GP-FANS/N 80M934-UP
Group No: 125-5065
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5S9062 | 1 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 1255062 | 2 BRACKET AS-FAN | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 4N0955 | DOWEL | 1 | |
| 8T8919 | 3 BOLT (1/2-13X1.75-IN) | 2 | |
| 5S2106 | 4 SEAL-LIP TYPE | 1 | |
| 8T4223 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5N4751 | 6 V-BELT SET (INCLUDES 3-BELTS)(FAN) | 1 | |
| 3B8489 | 7 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 8T9391 | 8 BOLT (1/2-13X3.75-IN) | 2 | |
| 6N4111 | 9 BRACKET AS | 1 | |
| 8H9789 | 10 BALL BEARING | 1 | |
| 8K4037 | 11 HOSE AS | 1 | |
| 8N5305 | 12 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 8L5008 | 13 ELBOW-PIPE | 1 | |
| 8T9101 | 14 BOLT (3/8-16X2.75-IN) | 6 | |
| 6V8801 | 15 NUT (3/8-16-THD) | 6 | |
| 7N1275 | 16 PULLEY-FAN DRIVE | 1 | |
| 9F4446 | 17 SEAL-O-RING | 1 | |
| 3L1425 | 18 BALL BEARING | 1 | |
| 7N2900 | 19 RETAINER (0.5MM THK) | 1 | |
| 7F0938 | 20 BOLT (5/16-24X3.25-IN) | 2 | |
| 9B7237 | 21 BOLT (3/8-16X1.25-IN) | 1 | |
| 2W2277 | 22 ADAPTER-FAN | 1 | |
| 2P1757 | 23 HUB-FAN PULLEY | 1 | |
| 8T4896 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T6761 | 25 PLUG-PIPE (1-11-1/2 NPT THD) | 1 |
