System And Components
191-3077 LINES GP-AIR COMPRESSORS/N 5JJ1-3670
Group No: 191-3077
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3R2705 | 1 UNION-FLARED | 1 | |
| 4W1117 | 2 ADAPTER | 1 | |
| 7C0307 | 3 GASKET | 1 | |
| 7W3447 | 4 SPACER (10.2X19.05X10.2-MM THK) | 1 | |
| 8M7065 | 5 GASKET (AIR INLET) | 1 | |
| 9G4918 | 6 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 7N1577 | BRACKET | 1 | |
| 0340912 | 7 TUBE | 1 | |
| 1182763 | 8 TUBE AS | 1 | |
| 1358289 | 9 HOSE AS | 1 | |
| 1765647 | 10 PLATE | 1 | |
| 1765648 | 11 TUBE AS | 1 | |
| 1919383 | 12 TUBE AS | 1 | |
| 1966013 | 13 TUBE AS | 1 | |
| 0047626 | 14 CONNECTOR (FLARED) | 1 | |
| 0307949 | 15 ELBOW | 1 | |
| 0307950 | 16 ELBOW | 1 | |
| 0308195 | 17 CONNECTOR | 1 | |
| 0321269 | 18 ELBOW | 1 | |
| 0L2070 | 19 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S0509 | 20 BOLT (3/8-16X0.75-IN) | 1 | |
| 1653931 | 21 BOLT (3/8-16X1.75-IN) | 1 | |
| 1653929 | 22 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1617 | 23 BOLT (5/16-18X0.75-IN) | 2 | |
| 1144427 | 24 SEAL-O-RING | 1 | |
| 1B8471 | 25 CLIP | 1 | |
| 2N1287 | 26 ELBOW-FLARED | 1 | |
| 2N1288 | 27 ELBOW | 1 | |
| 3D2824 | 28 SEAL-O-RING | 1 | |
| 3R5387 | 29 CONNECTOR | 1 | |
| 5M2894 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 1367227 | 31 SEAL-O-RING | 1 | |
| 8M2772 | 32 CLIP (LOOP) | 1 | |
| 8T6764 | 33 PLUG-PIPE (1/8-27-THD) | 1 |
