System And Components
140-8488 PANEL GP-INSTRUMENTS/N 8AS1-179
Group No: 140-8488
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1253367 | 1 PANEL | 1 | |
| 1410704 | 2 FILM-INFORMATION (INSTRUMENT PANEL) | 1 | |
| 1466293 | 3 CONTROL GP-MONITOR (CATERPILLAR MONITORING SYSTEM) | 1 | |
| 1666926 | 4 MODULE GP-QUAD GAUGE | 1 | |
| 3E3383 | WEDGE-RECEPTACLE LOCK (6-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 1129095 | 5 FILM-IDENTIFICATION (CATERPILLAR MONITORING SYSTEM) | 1 | |
| 7Y7388 | 6 SCREW-BUTTON HEAD (M5X0.8X12-MM) | 12 | |
| 1636509 | 7 LAMP-LED (24-VOLT, WHITE) | 2 | |
| 9W0335 | 8 LIGHTER AS-CIGAR (24-VOLT) | 1 | |
| 1107887 | 9 SWITCH AS-START (KEY) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 3E3377 | WEDGE-RECEPTACLE LOCK (4-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 3E8769 | 10 SWITCH AS (24-VOLT)(HEADLAMP)(ILLUMINATED/24V) | 1 | |
| 3E8814 | ACTUATOR | 1 | |
| 1655674 | LAMP-LED (24-VOLT) | 1 | |
| 3E8857 | 11 SWITCH AS-ROCKER (SECONDARY STEERING/BRK RELEASE) | 1 | |
| 1282635 | ACTUATOR | 1 | |
| 1655674 | LAMP-LED (24-VOLT) | 1 | |
| 3E8768 | 12 SWITCH AS (24-VOLT)(CAT MON SYS MODE)(ILLUM/24V) | 1 | |
| 1126170 | ACTUATOR | 1 | |
| 1655674 | LAMP-LED (24-VOLT) | 1 | |
| 3E0109 | 13 PLUG (ROCKER SWITCH) | 4 | |
| 1570217 | 14 SWITCH AS-ROTARY (BLOWER) | 1 | |
| 9B7233 | LOCKWASHER | 6 | |
| 6V8362 | SCREW-MACHINE (8-32X0.31-IN) | 6 | |
| 2P4339 | 15 NUT-JAM (7/16-28-THD) | 1 | |
| 1106109 | 16 KNOB-CONTROL (BLOWER SPEED) | 1 | |
| 1631880 | 17 LAMP-LED (24-VOLT, BLUE) | 1 | |
| 7T1874 | 18 TERMINAL-BLADE | 6 | |
| 1631878 | 19 LAMP-LED (24-VOLT, YELLOW) | 4 | |
| 4L6454 | 20 BOLT (3/8-16X1-IN) | 1 | |
| 1726774 | 21 HARNESS AS-MONITOR (CATERPILLAR MONITORING SYSTEM) | 1 | |
| 4P7581 | 22 CLIP (LADDER) | 2 | |
| 3S2093 | 23 STRAP-CABLE | 6 | |
| 1722358 | 24 HARNESS AS-DASH (MAIN) | 1 | |
| 1169309 | 25 HARNESS AS-WIRING (RETARDER)(JUMPER W/O AUTO RETARDER CTL) | 1 | |
| 9L1775 | 26 BRACKET | 1 | |
| 9X2042 | 27 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 1S0994 | 28 CLIP (LOOP) | 1 | |
| 8T4896 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 6V8801 | 30 NUT (3/8-16-THD) | 1 | |
| 7K1181 | 31 STRAP-CABLE | 4 | |
| 4P8134 | 32 CLIP (LADDER) | 1 | |
| 1280315 | 33 TRAY | 1 | |
| 3E8859 | 34 SWITCH AS (NOISE REDUCTION)(ILLUM/24V) | 1 | |
| 1655674 | LAMP-LED (24-VOLT) | 2 | |
| 1460237 | ACTUATOR | 1 | |
| 1160118 | 35 CLIP | 1 | |
| 9D3737 | 36 PLUG-BUTTON | 1 | |
| 7F6998 | 37 LOCKWASHER | 1 | |
| 1631879 | 38 LAMP-LED (24-VOLT, GREEN) | 2 | |
| 1631876 | 39 LAMP-LED (24-VOLT, RED) | 2 | |
| 1636508 | 40 LAMP-LED (24-VOLT, WHITE) | 2 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 |
