183-4464 PANEL GP-INSTRUMENTS/N 8AS206-UP

Group No: 183-4464

Part Number	Part Name	Qty
2P4339	1 NUT-JAM (7/16-28-THD)	1
3E0109	2 PLUG (ROCKER SWITCH)	4
3S2093	3 STRAP-CABLE	6
7K1181	4 STRAP-CABLE	4
7T1874	5 TERMINAL-BLADE	6
1106109	6 KNOB-CONTROL (FAN SPEED)	1
1107887	7 SWITCH AS-START (KEY)	1
1028804	KIT-RECEPTACLE (4-PIN)	1
7T6799	NUT-MOUNTING (1-32-THD)	1
1863735	PIN-CONNECTOR (16-GA TO 18-GA)	4
1129095	8 FILM-IDENTIFICATION (CATERPILLAR MONITORING SYSTEM)	1
1160118	9 CLIP	1
1169309	10 HARNESS AS-WIRING (RETARDER)	1
1552271	KIT-CONNECTING PLUG (4-PIN)	1
1253367	11 PANEL	1
1280315	12 TRAY	1
1410704	13 FILM-INFORMATION (INSTRUMENT PANEL)	1
1570217	14 SWITCH AS-ROTARY (FAN SPEED)	1
6V8362	SCREW-MACHINE (8-32X0.31-IN)	6
9B7233	LOCKWASHER	6
1631876	15 LAMP-LED (24-VOLT, RED)(ACTION)	2
1631878	16 LAMP-LED (24-VOLT, YELLOW)(DASH INDICATOR)	4
1631879	17 LAMP-LED (24-VOLT, GREEN)(TURN SIGNAL)	2
1631880	18 LAMP-LED (24-VOLT, BLUE)(HIGH BEAM)	1
1636508	19 LAMP-LED (24-VOLT, WHITE)(DASH)	2
1636509	20 LAMP-LED (24-VOLT, WHITE)(GAUGES)	2
1666926	21 MODULE GP-QUAD GAUGE	1
1701305	22 SWITCH AS-ROCKER (HEADLAMP)	1
1701307	23 SWITCH AS-ROCKER (24-VOLT)(CATERPILLAR MONITORING SYSTEM)	1
1701327	24 SWITCH AS-ROCKER (BODY UP, ENG NOISE REDUCTION)	1
1701331	25 SWITCH AS-ROCKER (SUPPLEMENTAL STEERING)	1
1726774	26 HARNESS AS-MONITOR (CATERPILLAR MONITORING SYSTEM)	1
8T9834	PLUG AS-CONNECTOR (40-PIN)	1
1552274	KIT-CONNECTING PLUG (6-PIN)	3
7X6222	PLUG AS-CONNECTOR (24-PIN)	1
1731069	27 HARNESS AS-PANEL	1
1028804	KIT-RECEPTACLE (4-PIN)	1
1552271	KIT-CONNECTING PLUG (4-PIN)	1
1130580	RECEPTACLE AS-CONNECTOR (40-PIN)	1
1833561	28 CONTROL GP-MONITOR (CATERPILLAR MONITORING SYSTEM)	1
4P7581	29 CLIP (LADDER)	2
4P8134	30 CLIP (LADDER)	1
7F6998	31 LOCKWASHER	1
7Y7388	32 SCREW-BUTTON HEAD (M5X0.8X12-MM)	12
9D3737	33 PLUG-BUTTON	1
9W0335	34 LIGHTER AS-CIGAR (24-VOLT)	1
9X2042	35 SCREW-TRUSS HEAD (M6X1X12-MM)	3
