System And Components
7E-5337 LINES GP-TURBOCHARGER OILS/N 7TR1-1202
Group No: 7E-5337
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N5094 | 1 ELBOW-DRAIN | 4 | |
| 5P9890 | 2 SEAL-O-RING | 8 | |
| 7E5338 | 3 TUBE | 2 | |
| 7E5335 | 4 BRACKET | 4 | |
| 6K5535 | 5 CLIP (SLOT) | 4 | |
| 6K5536 | 6 CLIP (TAB) | 4 | |
| 0S1594 | 7 BOLT (3/8-16X1-IN) | 4 | |
| 3E4352 | 8 WASHER-HARD (8.8X20.5X2.5-MM THK) | 12 | |
| 9S8752 | 9 NUT-FULL (3/8-16-THD) | 16 | |
| 9Y5814 | 10 ELBOW-DRAIN | 4 | |
| 7N7559 | 11 GASKET | 4 | |
| 0T0055 | 12 BOLT (3/8-16X4.25-IN) | 6 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 20 | |
| 1W7990 | 14 TUBE | 2 | |
| 0S1588 | 15 BOLT (3/8-16X1.25-IN) | 16 | |
| 2W0752 | 16 GASKET | 4 | |
| 0307949 | 17 ELBOW | 1 | |
| 6V4589 | 18 SEAL-O-RING | 2 | |
| 4P0692 | 19 CLAMP AS | 24 | |
| 0S1617 | 20 BOLT (5/16-18X0.75-IN) | 12 | |
| 0038581 | 21 TEE-UNION | 2 | |
| 7E5330 | 22 BRACKET | 12 | |
| 9M4584 | 23 CONNECTOR | 1 | |
| 7E0949 | 24 TUBE AS | 1 | |
| 7E0950 | 25 TUBE AS | 1 | |
| 0L1143 | 26 BOLT (3/8-16X2.5-IN) | 12 | |
| 3B1915 | 27 BOLT (3/8-16X1.375-IN) | 4 | |
| 0S1608 | 28 BOLT (3/8-16X3.75-IN) | 4 | |
| 1843230 | 29 HOSE AS | 4 | |
| 6I0812 | 30 TUBE AS-OIL | 2 | |
| 4P4460 | 31 GASKET | 4 | |
| 9X6458 | 32 WASHER-HARD (10.2X22.5X3-MM THK) | 20 | |
| 6I0805 | 33 ADAPTER-TURBOCHARGER OIL | 2 | |
| 6I0804 | 34 ADAPTER-TURBOCHARGER OIL | 2 | |
| 8L2786 | 35 SEAL-O-RING | 4 | |
| 2P7636 | 36 CONNECTOR (3/4-16 STR-THD) | 4 | |
| 5P4900 | 37 ELBOW-FLARED | 2 | |
| 8S9191 | 38 BOLT (3/8-16X4-IN) | 2 | |
| 9R5008 | 39 SPACER (11X20X6-MM THK) | 2 |
