System And Components
7E-5337 LINES GP-TURBOCHARGER OILS/N 7TR1203-3562
Group No: 7E-5337
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W0752 | 1 GASKET | 4 | |
| 4P0692 | 2 CLAMP AS | 22 | |
| 1081434 | GROMMET | 1 | |
| 4P4460 | 3 GASKET | 4 | |
| 6I0804 | 4 ADAPTER-TURBOCHARGER OIL | 2 | |
| 6I0805 | 5 ADAPTER-TURBOCHARGER OIL | 2 | |
| 6I0812 | 6 TUBE AS-OIL | 2 | |
| 6K5535 | 7 CLIP (SLOT) | 4 | |
| 6K5536 | 8 CLIP (TAB) | 4 | |
| 7E0949 | 9 TUBE AS | 1 | |
| 7E5330 | 10 BRACKET | 11 | |
| 7E5335 | 11 BRACKET | 4 | |
| 7N5094 | 12 ELBOW-DRAIN | 4 | |
| 7N7559 | 13 GASKET | 4 | |
| 9R5008 | 14 SPACER (11X20X6-MM THK) | 2 | |
| 9Y0047 | 15 CLAMP | 2 | |
| 9Y5814 | 16 ELBOW-DRAIN | 4 | |
| 1843230 | 17 HOSE AS | 4 | |
| 2054782 | 18 TUBE AS | 1 | |
| 2789542 | 19 TUBE (LH) | 2 | |
| 2789544 | 20 TUBE (RH) | 2 | |
| 0038581 | 21 TEE-UNION | 2 | |
| 2501498 | 22 ELBOW AS | 1 | |
| 6V4589 | SEAL-O-RING | 1 | |
| 2501497 | ELBOW | 1 | |
| 0L1143 | 23 BOLT (3/8-16X2.5-IN) | 11 | |
| 0S1588 | 24 BOLT (3/8-16X1.25-IN) | 16 | |
| 0S1594 | 25 BOLT (3/8-16X1-IN) | 4 | |
| 0S1608 | 26 BOLT (3/8-16X3.75-IN) | 4 | |
| 0S1617 | 27 BOLT (5/16-18X0.75-IN) | 11 | |
| 0T0055 | 28 BOLT (3/8-16X4.25-IN) | 6 | |
| 1003237 | 29 GROMMET | 2 | |
| 2B2694 | 30 BOLT (5/16-18X2-IN) | 1 | |
| 2P7636 | 31 CONNECTOR (3/4-16 STR-THD) | 4 | |
| 3B1915 | 32 BOLT (3/8-16X1.375-IN) | 4 | |
| 3E4352 | 33 WASHER-HARD (8.8X20.5X2.5-MM THK) | 11 | |
| 5M2894 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 19 | |
| 2501496 | 35 ELBOW | 2 | |
| 1123540 | 36 SEAL-O-RING | 8 | |
| 2385081 | 37 SEAL-O-RING | 1 | |
| 2385080 | 38 SEAL-O-RING | 4 | |
| 8S9191 | 39 BOLT (3/8-16X4-IN) | 2 | |
| 9L9132 | 40 WASHER-HARD (10.2X25.5X2.5-MM THK) | 8 | |
| 9M4584 | 41 CONNECTOR | 1 | |
| 9N0869 | 42 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 9S8752 | 43 NUT-FULL (3/8-16-THD) | 15 | |
| 9X6458 | 44 WASHER-HARD (10.2X22.5X3-MM THK) | 11 |
