System And Components
175-5270 LINES GP-TURBOCHARGER WATERS/N 7TR1108-1338
Group No: 175-5270
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9S8896 | 1 CAP (FLARED 37-DEG) | 2 | |
| 4P0693 | 2 CLAMP AS | 2 | |
| 6K8420 | 3 LOCKNUT (1-1/16-12-THD) | 2 | |
| 7F2060 | 4 LOCKNUT (7/8-14-THD) | 2 | |
| 7N7878 | 5 PLATE-COVER | 8 | |
| 1070744 | 6 BLOCK | 4 | |
| 1537482 | 7 BRACKET | 2 | |
| 1537491 | 8 TUBE AS | 1 | |
| 1537492 | 9 TUBE AS | 1 | |
| 1537493 | 10 TUBE AS | 2 | |
| 1537499 | 11 TUBE AS | 2 | |
| 1537500 | 12 TUBE AS | 1 | |
| 1537505 | 13 BRACKET | 2 | |
| 1537506 | 14 TUBE AS | 1 | |
| 1550515 | 15 ELBOW | 4 | |
| 1755246 | 16 TUBE AS | 1 | |
| 1755247 | 17 TUBE AS | 1 | |
| 1755249 | 18 BRACKET AS | 1 | |
| 3419211 | 19 GASKET | 16 | |
| 2501498 | 20 ELBOW AS | 2 | |
| 6V4589 | SEAL-O-RING | 1 | |
| 2501497 | ELBOW | 1 | |
| 2501499 | 21 TEE | 2 | |
| 0L2070 | 22 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1608 | 23 BOLT (3/8-16X3.75-IN) | 4 | |
| 2A4639 | 24 BOLT (3/8-16X1.625-IN) | 16 | |
| 2P1326 | 25 ELBOW-UNION (FLARED 90-DEG) | 2 | |
| 2P7636 | 26 CONNECTOR (3/4-16 STR-THD) | 4 | |
| 3B1915 | 27 BOLT (3/8-16X1.375-IN) | 12 | |
| 5M2894 | 28 WASHER-HARD (10.2X18.5X2.5-MM THK) | 33 | |
| 5P1945 | 29 REDUCER-FLARED | 4 | |
| 5P7154 | 30 TEE-UNION | 2 | |
| 6V4589 | 31 SEAL-O-RING | 4 | |
| 8L2786 | 32 SEAL-O-RING | 4 | |
| 9M4584 | 33 CONNECTOR | 2 | |
| 1L5081 | 34 SPACER (0.41X0.75X0.56-IN THK) | 16 |
