System And Components
513-2609 BELT TIGHTENER GPS/N 2PZ1-UP
Group No: 513-2609
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M2742 | 1 PLATE-RETAINER | 1 | |
| 2V0460 | 2 HOSE AS | 1 | |
| 4W4448 | 3 PULLEY-IDLER | 1 | |
| 4W4456 | 4 ARM AS-TIGHTENER | 1 | |
| 4S5367 | 4A BUSHING AS (MOUNT) | 1 | |
| 2D6642 | BALL | 1 | |
| 5B9318 | BALL | 1 | |
| 5M7937 | DOWEL | 1 | |
| 6U1989 | 5 VALVE-RELIEF | 1 | |
| 7W8460 | 6 WASHER-RETAINING | 1 | |
| 8L5008 | 7 ELBOW-PIPE | 1 | |
| 8N9409 | 8 COVER | 1 | |
| 8N9410 | 9 SPACER | 1 | |
| 8N9419 | 10 SPACER (18.25-MM THK) | 1 | |
| 2350279 | 11 BRACKET AS | 1 | |
| 3446306 | 12 SPRING | 2 | |
| 0L2070 | 13 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 1 | |
| 0S1595 | 15 BOLT (1/2-13X1.25-IN) | 2 | |
| 0S1617 | 16 BOLT (5/16-18X0.75-IN) | 4 | |
| 2N8374 | 17 GASKET | 1 | |
| 3B4617 | 18 PIN-COTTER | 2 | |
| 3V3308 | 19 WASHER-HARD (10.2X20.5X2.5-MM THK) | 1 | |
| 4B5006 | 20 FITTING-GREASE | 1 | |
| 4D1326 | 21 LOCKWASHER | 1 | |
| 4D7794 | 22 CLIP | 1 | |
| 5M2057 | 23 SEAL-O-RING | 1 | |
| 5P8245 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 5S2106 | 25 SEAL-LIP TYPE | 1 | |
| 8B1419 | 26 PIN-CLEVIS | 2 | |
| 8H9789 | 27 BALL BEARING | 2 | |
| 8T4896 | 28 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9M1974 | 29 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S1374 | 30 BOLT (1/2-13X8-IN) | 2 |
