System And Components
240-6651 CYLINDER BLOCK GPS/N 8BR2357-2515
Group No: 240-6651
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3501413 | 1 CYLINDER BLOCK AS | 1 | |
| 1011198 | 3 BEARING-CAMSHAFT | 14 | |
| 1A2029 | 4 BOLT (3/8-16X1.125-IN) | 1 | |
| 7X7731 | 5 PLUG-PIPE (3/4-14-THD) | 1 | |
| 9S4191 | 6 PLUG (9/16-18-THD) | 6 | |
| 2W2940 | 7 PLUG (OIL MANIFOLD) | 8 | |
| 7N2044 | 8 DOWEL | 2 | |
| 8T6762 | 9 PLUG-PIPE (1/2-14-THD) | 4 | |
| 5M2894 | 10 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 7N2047 | 11 DOWEL | 3 | |
| 7X4805 | 12 SEAL-O-RING | 3 | |
| 4N0683 | 16 DOWEL | 2 | |
| 8T6763 | 17 PLUG-PIPE (1/4-18-THD) | 22 | |
| 8T0099 | 19 DOWEL | 24 | |
| 7N5641 | 20 PLUG-MANIFOLD | 2 | |
| 1977008 | 21 DOWEL | 12 | |
| 5P0840 | 22 SEAL-O-RING | 24 | |
| 1445692 | 23 GASKET-PLATE | 12 | |
| 1106994 | 24 PLATE-SPACER | 12 | |
| 5F9657 | 25 SEAL-O-RING | 4 | |
| 5P8210 | 26 SEAL-O-RING | 1 | |
| 0S1595 | 27 BOLT (1/2-13X1.25-IN) | 1 | |
| 5P8245 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8N8056 | 29 COVER | 1 | |
| 6V3348 | 30 SEAL-O-RING | 8 | |
| 2147568 | 34 SEAL-O-RING | 6 | |
| 0S1595 | 35 BOLT (1/2-13X1.25-IN) | 1 | |
| 1A2029 | 36 BOLT (3/8-16X1.125-IN) | 1 | |
| 5M2894 | 37 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P8210 | 38 SEAL-O-RING | 1 | |
| 5P8245 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 7X7731 | 40 PLUG-PIPE (3/4-14-THD) | 1 | |
| 8N8056 | 41 COVER | 1 |
