System And Components
152-1028 DRIVE GP-AUXILIARY -WATER PUMPS/N 8BR605-940
Group No: 152-1028
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5R7136 | 1 WASHER-SEALING | 1 | |
| 5R7137 | 2 WASHER-SEALING | 2 | |
| 7C3258 | 3 WASHER AS-THRUST | 1 | |
| 7N2047 | DOWEL | 1 | |
| 7C3260 | 4 SHAFT | 1 | |
| 7E0275 | 5 GEAR-WATER PUMP DRIVE (69-TEETH) | 1 | |
| 7N7539 | 6 WASHER-THRUST | 2 | |
| 1448263 | 8 GEAR AS-IDLER (53-TEETH) | 1 | |
| 1409597 | BUSHING | 1 | |
| 1470827 | 9 ADAPTER AS | 1 | |
| 7C7808 | SEAL-LIP TYPE | 1 | |
| 8T6759 | PLUG-PIPE | 2 | |
| 1275400 | BUSHING | 1 | |
| 1566214 | 10 SHAFT AS | 1 | |
| 0T0055 | 11 BOLT (3/8-16X4.25-IN) | 1 | |
| 1T0720 | 12 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 4 | |
| 2B2695 | 13 BOLT (5/16-18X0.875-IN) | 4 | |
| 5P0840 | 14 SEAL-O-RING | 1 | |
| 5M2894 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P8245 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 9M1974 | 17 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X8879 | 18 BOLT (1/2-13X5.5-IN) | 2 | |
| 2594598 | 19 SEAL-O-RING | 2 |
