System And Components
160-9850 DRIVE GP-FAN -HIGH ALTITUDE APPLICATION-VARIABLE SPEEDS/N 2PZ1-UP
Group No: 160-9850
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1008028 | 1 PULLEY-FAN DRIVE | 1 | |
| 1632592 | 2 DRIVE GP-FAN (VARIABLE SPEED) | 1 | |
| 1299474 | 3 SPACER (50.8-MM THK) | 1 | |
| 0S1588 | 4 BOLT (3/8-16X1.25-IN) | 8 | |
| 3B8686 | 5 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 9Y5010 | 6 ADAPTER-GREASE | 1 | |
| 8T6764 | 7 PLUG-PIPE (1/8-27-THD) | 1 | |
| 2A4639 | 8 BOLT (3/8-16X1.625-IN) | 2 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 4M2442 | 10 BOLT (1/2-13X12.32-IN) | 4 | |
| 5P8245 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 9M7269 | 12 BOLT (1/2-13X6.75-IN) | 2 | |
| 3198058 | 13 BRACKET AS | 1 | |
| 1114379 | SHAFT-TIGHTENER | 1 | |
| 3198057 | BRACKET | 1 | |
| 3242416 | PIN-ROLL | 1 | |
| 5P8248 | 14 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 8C6857 | 15 BOLT (3/4-10X2.75-IN) | 4 | |
| 0S1573 | 16 BOLT (1/2-13X4-IN) | 8 | |
| 1435123 | 17 HARNESS AS-SENSOR (RESISTOR)(ENGINE) | 1 | |
| 9X6772 | 18 STRAP-CABLE | 2 |
