System And Components
175-5209 AIR CLEANER GPS/N 2PZ1-105
Group No: 175-5209
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N8161 | 2 NUT-WING | 1 | |
| 1S5465 | 3 GUARD-DUST | 1 | |
| 1S5485 | 4 VALVE-DUST | 1 | |
| 3R5819 | 5 SHROUD AS | 1 | |
| 4W5295 | 7 CUP AS-PRECLEANER | 1 | |
| 5S4279 | 8 GASKET | 1 | |
| 6L3314 | 9 CLAMP AS (UPPER) | 1 | |
| 6L3316 | 10 CLAMP AS (LOWER) | 1 | |
| 7W0442 | 11 BODY AS-PRECLEANER | 1 | |
| 7W0444 | 12 NUT AS | 1 | |
| 7W0481 | 13 GASKET | 4 | |
| 9M7959 | 14 CLAMP-HOSE | 1 | |
| 0066850 | 15 RETAINER (RING) | 1 | |
| 1779074 | 16 AIR CLEANER AS | 1 | |
| 1N4864 | 16A FILTER ELEMENT-AIR (SECONDARY) | 1 | |
| 4W5228 | 16B FILTER ELEMENT-AIR (PRIMARY) | 1 | |
| 1779075 | 17 BAND AS | 1 | |
| 0S1591 | BOLT (3/8-16X1.5-IN) | 1 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 1 | |
| 3B4618 | 18 PIN-COTTER | 1 | |
| 5L2692 | 19 GASKET | 2 |
