Assembly
100%

103-0942 LINES GP-AIRS/N 8BR1-UP

Group No: 103-0942
Part NumberPart NameQty
1S11501 SPACER (0.391X0.5X0.19-IN THK)12
2N27652 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)8
4W02263 ADAPTER2
2N27664 LOCKNUT (3/8-16-THD)8
7C79095 ELBOW (AIR INLET)10
7C79106 ELBOW (AIR INLET)2
7C81997 FLANGE12
9X64588 WASHER-HARD (10.2X22.5X3-MM THK)4
7N50809 GASKET-MANIFOLD12
7N508710 GASKET2
7W314511 PLATE4
1A146012 BOLT (1/2-13X2-IN)4
283959913 MANIFOLD (AIR INLET)1
123697914 CLAMP-V BAND2
127811215 SUPPORT-EXHAUST PIPE (LH)1
127811316 SUPPORT-EXHAUST PIPE (RH)1
129952717 BAR2
348566118 PLATE1
146738319 FLANGE2
155043720 COVER1
155054421 ELBOW1
155054522 ELBOW1
156626123 BRACKET2
156983024 ELBOW (AIR INLET)1
160984325 ADAPTER2
160984426 ELBOW (AIR INLET)1
165419027 COUPLING-ELBOW2
168780028 LOCKNUT (3/8-16-THD)12
0S050929 BOLT (3/8-16X0.75-IN)6
0S159030 BOLT (3/8-16X2-IN)6
165392931 BOLT (3/8-16X1.5-IN)24
0S159432 BOLT (3/8-16X1-IN)12
0S161933 BOLT (3/8-16X3-IN)2
0T057334 BOLT (3/8-16X2.75-IN)2
109741135 SEAL-O-RING2
1A202936 BOLT (3/8-16X1.125-IN)2
1T072037 BOLT-12 POINT HEAD (3/8-16X1.25-IN)48
2A463938 BOLT (3/8-16X1.625-IN)24
4S589839 SEAL-O-RING12
5D595740 SEAL-O-RING2
5M289441 WASHER-HARD (10.2X18.5X2.5-MM THK)118
6V391742 SEAL-O-RING8
6V510143 SEAL-O-RING12
7L319544 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)12
5P824545 WASHER-HARD (13.5X25.5X3-MM THK)4
8T676246 PLUG-PIPE (1/2-14-THD)6
8T676447 PLUG-PIPE (1/8-27-THD)4
9F277348 BOLT (3/8-16X8.5-IN)10
