177-9059 LINES GP-AIRS/N 8BR605-UP

Group No: 177-9059
Part NumberPart NameQty
1S11501 SPACER (0.391X0.5X0.19-IN THK)12
2N27652 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)8
4W02263 ADAPTER2
7C79094 ELBOW (AIR INLET)10
7C79105 ELBOW (AIR INLET)2
7C81996 FLANGE12
7N50807 GASKET-MANIFOLD12
7N50878 GASKET2
7W31459 PLATE4
123697910 CLAMP-V BAND2
127811211 SUPPORT-EXHAUST PIPE (LH)1
127811312 SUPPORT-EXHAUST PIPE (RH)1
129952713 BAR2
348566114 PLATE1
146738315 FLANGE2
155043716 COVER1
155054417 ELBOW1
155054518 ELBOW1
156626119 BRACKET2
165419020 COUPLING-ELBOW2
168780021 LOCKNUT (3/8-16-THD)12
283959922 MANIFOLD (AIR INLET)1
180742823 ADAPTER1
156983024 ELBOW1
186417125 ELBOW (AIR INLET)1
0S050926 BOLT (3/8-16X0.75-IN)6
0S159027 BOLT (3/8-16X2-IN)6
165392928 BOLT (3/8-16X1.5-IN)24
0S159429 BOLT (3/8-16X1-IN)10
0S161930 BOLT (3/8-16X3-IN)2
0T057331 BOLT (3/8-16X2.75-IN)2
109741132 SEAL-O-RING2
1A202933 BOLT (3/8-16X1.125-IN)2
1T072034 BOLT-12 POINT HEAD (3/8-16X1.25-IN)48
2A463935 BOLT (3/8-16X1.625-IN)24
4S589836 SEAL-O-RING12
5D595737 SEAL-O-RING2
5M289438 WASHER-HARD (10.2X18.5X2.5-MM THK)130
5P824539 WASHER-HARD (13.5X25.5X3-MM THK)2
6V391740 SEAL-O-RING8
6V510141 SEAL-O-RING12
7L319542 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)12
8T676244 PLUG-PIPE (1/2-14-THD)6
8T676445 PLUG-PIPE (1/8-27-THD)2
9F277346 BOLT (3/8-16X8.5-IN)10
9X645848 WASHER-HARD (10.2X22.5X3-MM THK)4
2B200649 BOLT (1/2-13X4.75-IN)2
2N276651 LOCKNUT (3/8-16-THD)8
