System And Components
129-2194 DRIVE GP-FAN -VARIABLE SPEEDS/N 2BW1-UP
Group No: 129-2194
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1008029 | 1 PULLEY-FAN DRIVE | 1 | |
| 1098086 | 2 BRACKET-SHAFT | 1 | |
| 3B1915 | 3 BOLT (3/8-16X1.375-IN) | 8 | |
| 9M7269 | 4 BOLT (1/2-13X6.75-IN) | 2 | |
| 8C6857 | 5 BOLT (3/4-10X2.75-IN) | 4 | |
| 5P8245 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 5P8248 | 7 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 4M2442 | 8 BOLT (1/2-13X12.32-IN) | 4 | |
| 3B8686 | 9 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 9Y5010 | 10 ADAPTER-GREASE | 1 | |
| 8T6764 | 11 PLUG-PIPE (1/8-27-THD) | 1 | |
| 2A4639 | 12 BOLT (3/8-16X1.625-IN) | 2 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 1335969 | 14 DRIVE GP-FAN (VARIABLE SPEED) | 1 | |
| 9X6772 | 15 STRAP-CABLE | 2 | |
| 1435123 | 16 HARNESS AS-SENSOR (RESISTOR)(VARIABLE SPEED FAN DRIVE) | 1 | |
| 1028807 | KIT-CONNECTING PLUG (2-PIN)(FAN DRIVE HARNESS) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028808 | KIT-CONNECTING PLUG (3-PIN)(FAN DRIVE HARNESS) | 1 |
