Assembly
100%

381-8703 LINES GP-ENGINE OILS/N 7TR3563-UP

Group No: 381-8703
Part NumberPart NameQty
1N33331 TUBE1
1W24472 ADAPTER-OUTLET1
2W16353 SPRING1
2W19694 VALVE-BYPASS (OIL COOLER)1
3P07645 PLUG1
4W58906 PLUG1
6B92027 SPRING2
7C92178 ELBOW (OIL COOLER BYPASS)1
7N54169 ELBOW (OUTLET)1
7N769710 PLUNGER AS (SEQUENCE VALVE)2
7M1808DOWEL1
361709711 RING1
8N199212 RETAINER2
8N292913 COVER2
9M459414 SPACER (0.406X0.875X0.75-IN THK)2
100807515 CLAMP AS1
445882616 TUBE AS1
111382017 RING-RETAINING1
264045018 CLAMP AS1
359412219 ELBOW1
359412320 ADAPTER (TURBOCHARGER OIL)1
369950921 ELBOW-OIL COOLER (INLET)1
0L114322 BOLT (3/8-16X2.5-IN)4
165393123 BOLT (3/8-16X1.75-IN)4
0S158824 BOLT (3/8-16X1.25-IN)10
165392925 BOLT (3/8-16X1.5-IN)2
0S159426 BOLT (3/8-16X1-IN)14
0T057327 BOLT (3/8-16X2.75-IN)2
109233228 SEAL-O-RING5
1A596429 BOLT (3/8-16X4.5-IN)4
2K497330 LOCKNUT (3/8-16-THD)2
3P065531 SEAL-O-RING3
4B314032 COVER1
4W559633 COVER (BYPASS VALVE)1
5F489934 BOLT (3/8-16X5.5-IN)1
5M289435 WASHER-HARD (10.2X18.5X2.5-MM THK)16
5P489236 SEAL-O-RING1
5P584637 SEAL-O-RING1
6B093338 SPACER (10.31X19.05X6.35-MM THK)4
6B507239 ADAPTER1
6V157240 CLIP (SLOT)2
6V157341 CLIP (TAB)2
6V157442 GROMMET2
6V390843 SEAL-O-RING1
6V436844 SEAL-O-RING4
6V458945 SEAL-O-RING1
6V504846 SEAL-O-RING2
8T676247 PLUG-PIPE (1/2-14-THD)1
8T676548 PLUG-PIPE (1/4-18-THD)4
9S418249 PLUG (7/16-20-THD)2
2W105350 PLUG1
228709751 SEAL-O-RING1
361709852 FLANGE1
