System And Components
386-0474 LINES GP-TURBOCHARGER WATERS/N 7TR3403-3661
Group No: 386-0474
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0693 | 1 CLAMP AS | 4 | |
| 1081434 | GROMMET | 2 | |
| 6K8420 | 2 LOCKNUT (1-1/16-12-THD) | 2 | |
| 7F2060 | 3 LOCKNUT (7/8-14-THD) | 2 | |
| 7N7878 | 4 PLATE-COVER | 8 | |
| 1070744 | 5 BLOCK | 4 | |
| 1537482 | 6 BRACKET | 2 | |
| 1550515 | 7 ELBOW | 4 | |
| 3419211 | 8 GASKET | 16 | |
| 3863385 | 9 BRACKET | 1 | |
| 3863386 | 10 BRACKET | 1 | |
| 3866229 | 11 ELBOW AS | 2 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2501497 | ELBOW | 1 | |
| 3867365 | 12 BRACKET AS | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3909089 | 13 BRACKET AS | 2 | |
| 3914572 | 14 BRACKET AS | 2 | |
| 0307972 | 15 ELBOW | 2 | |
| 0L2070 | 16 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 6 | |
| 0S1608 | 18 BOLT (3/8-16X3.75-IN) | 4 | |
| 2721777 | 19 WASHER-HARD (11X18.5X15-MM THK) | 16 | |
| 3650578 | 20 CONNECTOR AS | 4 | |
| 2P7636 | CONNECTOR (3/4-16 STR-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2A4639 | 21 BOLT (3/8-16X1.625-IN) | 20 | |
| 2P1296 | 22 TEE | 2 | |
| 2P1326 | 23 ELBOW-UNION (FLARED 90-DEG) | 2 | |
| 0307965 | 24 ELBOW | 1 | |
| 3537954 | 25 GROMMET | 4 | |
| 3867358 | 26 HOSE AS-WATER | 2 | |
| 0307964 | 27 ELBOW | 1 | |
| 4554775 | 28 HOSE & TUBE AS | 2 | |
| 1927402 | 29 HOSE AS | 2 | |
| 3867366 | 30 HOSE & TUBE AS | 2 | |
| 3867367 | 31 HOSE AS-WATER | 2 | |
| 3B1915 | 32 BOLT (3/8-16X1.375-IN) | 14 | |
| 5M2894 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 34 | |
| 5P1945 | 34 REDUCER-FLARED | 4 | |
| 5P7154 | 35 TEE-UNION | 2 | |
| 6V3251 | 36 SEAL-O-RING | 2 | |
| 8C8554 | 37 CONNECTOR | 2 | |
| 8M9024 | 38 WASHER-HARD (10.2X22.5X5-MM THK) | 8 | |
| 8T1889 | 39 CLIP (SLOT) | 4 | |
| 8T1890 | 40 CLIP (TAB) | 4 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 6B2882 | 42 SPACER (0.406X0.75X0.312-IN THK) | 2 |
