Assembly
100%

157-2818 LINES GP-AIR -AFTERCOOLERS/N 7TR1-UP

Group No: 157-2818
Part NumberPart NameQty
1W41611 CLAMP2
7C20232 ELBOW-EXHAUST2
7C79093 ELBOW (AIR INLET)14
7C79104 ELBOW (AIR INLET)2
7C81995 FLANGE16
7N50806 GASKET-MANIFOLD16
10974117 SEAL-O-RING4
11235918 COVER2
12135629 PIPE1
123691410 BAR2
123691511 PLATE1
146738312 FLANGE4
155054013 ELBOW (AIR INLET)1
155054114 ELBOW (AIR INLET)1
155054415 ELBOW2
155054516 ELBOW2
156626117 BRACKET4
156983018 ELBOW (AIR INLET)1
156983119 ELBOW1
160984320 ADAPTER2
283977921 MANIFOLD (INLET AIR)1
0S050922 BOLT (3/8-16X0.75-IN)6
0S158823 BOLT (3/8-16X1.25-IN)4
0S159024 BOLT (3/8-16X2-IN)8
165392925 BOLT (3/8-16X1.5-IN)32
0S159426 BOLT (3/8-16X1-IN)8
0S161927 BOLT (3/8-16X3-IN)4
0T057328 BOLT (3/8-16X2.75-IN)4
1A146029 BOLT (1/2-13X2-IN)4
1A202930 BOLT (3/8-16X1.125-IN)14
1T072031 BOLT-12 POINT HEAD (3/8-16X1.25-IN)64
2A463932 BOLT (3/8-16X1.625-IN)32
3J538933 PLUG (EXTERNAL)2
4S589834 SEAL-O-RING16
5D595735 SEAL-O-RING4
5M289436 WASHER-HARD (10.2X18.5X2.5-MM THK)168
5P824537 WASHER-HARD (13.5X25.5X3-MM THK)4
5P894038 SEAL-O-RING3
6V194339 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN)8
6V391740 SEAL-O-RING16
6V510141 SEAL-O-RING16
7W314542 PLATE8
8T676243 PLUG-PIPE (1/2-14-THD)7
8T676444 PLUG-PIPE (1/8-27-THD)4
9F277345 BOLT (3/8-16X8.5-IN)12
9X645846 WASHER-HARD (10.2X22.5X3-MM THK)8
5N443247 BOOT4
7C290148 COVER-ELBOW2
5P386049 CLAMP-HOSE4
