System And Components
249-0316 LINES GP-AIR -TURBOCHARGER, AIR CLEANERS/N 2BW704-UP
Group No: 249-0316
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P5104 | 1 ELBOW | 4 | |
| 4W1211 | 2 STRIP | 4 | |
| 5T6459 | 3 ELBOW | 2 | |
| 5T7873 | 4 BRACKET AS | 2 | |
| 5T7874 | STRAP | 1 | |
| 5T7874 | 5 STRAP | 2 | |
| 7E7790 | 6 HOSE | 2 | |
| 7N5008 | 7 HOSE | 2 | |
| 2444908 | 8 TUBE AS | 1 | |
| 2761327 | 9 SUPPORT AS | 4 | |
| 2493766 | 10 TUBE AS | 2 | |
| 2495090 | 11 TUBE AS | 2 | |
| 2495529 | 12 TUBE AS | 1 | |
| 0L1351 | 13 BOLT (3/8-16X0.875-IN) | 8 | |
| 0S1571 | 14 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1595 | 15 BOLT (1/2-13X1.25-IN) | 4 | |
| 2313264 | 16 CLAMP (BOLT SPRING) | 8 | |
| 2338483 | 17 CLAMP (BOLT SPRING) | 8 | |
| 2338484 | 18 CLAMP (BOLT SPRING) | 8 | |
| 2338485 | 19 CLAMP (BOLT SPRING) | 16 | |
| 2K4973 | 20 LOCKNUT (3/8-16-THD) | 8 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 5P8245 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 4 | |
| 9X2494 | 24 U-BOLT | 4 |
