System And Components
351-7635 PIPE GP-EXHAUSTS/N 2BW1668-UP
Group No: 351-7635
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5T2762 | 1 SPRING | 2 | |
| 5T3367 | 2 ELBOW | 2 | |
| 5T3369 | 3 PISTON | 2 | |
| 6G7031 | 4 ELBOW | 2 | |
| 6G7038 | 5 RING-SEAL | 2 | |
| 8W9351 | 6 BRACKET AS | 1 | |
| 8W9408 | 7 TUBE AS | 1 | |
| 9D2836 | 8 LOCK | 6 | |
| 3517569 | 9 PLATE | 4 | |
| 3517593 | 10 PLATE | 1 | |
| 3517594 | 11 PLATE | 8 | |
| 3517600 | 12 PLATE | 4 | |
| 3517627 | 13 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 3517628 | 14 PLATE AS | 1 | |
| 3523770 | 15 PLATE AS | 1 | |
| 3517569 | PLATE | 1 | |
| 9X6269 | NUT-WELD (M16X2-THD) | 2 | |
| 3K6060 | 16 LOCKNUT (3/8-16-THD) | 12 | |
| 1364182 | 17 BOLT (M16X2X100-MM) | 12 | |
| 1D5117 | 18 NUT-JAM (1/2-13-THD) | 4 | |
| 2678821 | 19 WASHER (17X36X12-MM THK) | 36 | |
| 2780460 | 20 BOLT (M16X2X120-MM) | 5 | |
| 3320035 | 21 ROD-THREADED (M16X2X150-MM) | 2 | |
| 4B3586 | 22 SETSCREW (1/2-13X2-IN) | 4 | |
| 4L6454 | 23 BOLT (3/8-16X1-IN) | 4 | |
| 5P1075 | 24 WASHER-HARD (10.2X22.5X3-MM THK) | 12 | |
| 5P2424 | 25 BOLT (1/2-13X2.25-IN) | 4 | |
| 7X0345 | 26 BOLT (5/8-11X1.75-IN) | 8 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4132 | 28 NUT (M16X2-THD) | 9 | |
| 8T4136 | 29 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4193 | 30 BOLT (M16X2X50-MM) | 4 | |
| 8T4223 | 31 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4896 | 32 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 2M4779 | 33 STUD-TAPERLOCK (3/8-16X1.75-IN) | 12 |
