System And Components
102-9792 DRIVE GP-FANS/N 7TR360-1253
Group No: 102-9792
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1026293 | 1 PULLEY | 1 | |
| 9Y2647 | 2 HUB-FAN PULLEY | 1 | |
| 4B4550 | 3 FITTING-PRESSURE RELIEF (1/8-27 PTF) | 1 | |
| 9Y9397 | 4 BRACKET AS | 1 | |
| 1138158 | SHAFT | 1 | |
| 9Y9388 | BRACKET-FAN DRIVE | 1 | |
| 8H9189 | DOWEL | 1 | |
| 1114379 | SHAFT-TIGHTENER | 1 | |
| 2A1538 | BOLT (3/4-10X2.25-IN) | 1 | |
| 5P8248 | WASHER-HARD (20X36.5X3.5-MM THK) | 1 | |
| 7W7590 | SLEEVE | 1 | |
| 7X3325 | 5 BOLT-LOCKING (1/2-13-THD) | 2 | |
| 7E2456 | 6 SPACER (76.207-MM THK) | 1 | |
| 2M0849 | 7 WASHER-HARD (13.5X25.5X5-MM THK) | 2 | |
| 5P8245 | 8 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 4P8134 | 9 CLIP (LADDER) | 3 | |
| 9X6772 | 10 STRAP-CABLE | 4 | |
| 9Y8465 | 11 PULLEY GP-CRANKSHAFT | 1 | |
| 6B8865 | KEY-WOODRUFF | 1 | |
| 7N7057 | 12 SHAFT-STUB | 1 | |
| 3B1915 | 13 BOLT (3/8-16X1.375-IN) | 8 | |
| 5F3144 | 14 SEAL-O-RING | 1 | |
| 6Y7651 | 15 CONE-BEARING | 2 | |
| 6Y7652 | 16 CUP-BEARING (TAPERED ROLLER) | 2 | |
| 7X7730 | 17 PLUG-PIPE | 1 | |
| 7E6854 | 18 ADAPTER | 1 | |
| 1J4034 | 19 SEAL-LIP TYPE | 1 | |
| 0S1571 | 20 BOLT (3/8-16X1.75-IN) | 12 | |
| 1029928 | 21 V-BELT SET (INCLUDES 6-BELTS)(CONSISTS OF 6 BELTS) | 1 | |
| 4M2442 | 22 BOLT (1/2-13X12.32-IN) | 4 | |
| 9M7269 | 23 BOLT (1/2-13X6.75-IN) | 2 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 2A4639 | 25 BOLT (3/8-16X1.625-IN) | 2 | |
| 5P8250 | 26 WASHER (28X49X5-MM THK) | 6 | |
| 3B8686 | 27 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 9Y5010 | 28 ADAPTER-GREASE | 1 | |
| 3B6552 | 29 ELBOW-PIPE | 1 | |
| 5T4789 | 30 HOSE AS | 1 | |
| 1138159 | 31 WASHER-RETAINING | 1 | |
| 9F8122 | 32 BOLT (1-14X9-IN) | 6 | |
| 4W5727 | KIT-BUSHING (CRANKSHAFT PULLEY)(FLANGED) | 1 |
