System And Components
142-8565 DRIVE GP-FANS/N 3TZ1-UP
Group No: 142-8565
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4M2442 | 1 BOLT (1/2-13X12.32-IN) | 4 | |
| 9M7269 | 2 BOLT (1/2-13X6.75-IN) | 2 | |
| 1098086 | 3 BRACKET-SHAFT | 1 | |
| 1335969 | 4 DRIVE GP-FAN | 1 | |
| 1417094 | 5 PULLEY-FAN | 1 | |
| 1435123 | 6 HARNESS AS-SENSOR (RESISTOR) | 1 | |
| 3B1915 | 7 BOLT (3/8-16X1.375-IN) | 8 | |
| 5P8245 | 8 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 5P8248 | 9 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 8C6857 | 10 BOLT (3/4-10X2.75-IN) | 4 | |
| 8T6764 | 11 PLUG-PIPE (1/8-27-THD) | 1 |
