System And Components
167-9574 HOUSING GP-FLYWHEELS/N 7TR360-UP
Group No: 167-9574
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5260837 | 1 HOUSING AS-FLYWHEEL | 1 | |
| 3F6795 | 1A DOWEL | 2 | |
| 3F6808 | 1B DOWEL | 1 | |
| 7N2047 | 1C DOWEL | 3 | |
| 4619988 | 1D HOUSING-FLYWHEEL | 1 | |
| 5P8245 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 19 | |
| 6V0405 | 3 SEAL-BONDED | 4 | |
| 5P4626 | 4 BOLT (5/8-11X10.5-IN) | 2 | |
| 0S1595 | 5 BOLT (1/2-13X1.25-IN) | 1 | |
| 8T6763 | 6 PLUG-PIPE (1/4-18-THD) | 5 | |
| 1D4574 | 7 BOLT (1/2-13X6-IN) | 8 | |
| 5D9514 | 8 BOLT (5/8-11X6.25-IN) | 12 | |
| 1D4597 | 9 BOLT (5/8-11X6.5-IN) | 1 | |
| 5P8247 | 10 WASHER-HARD (17X32X3.5-MM THK) | 15 | |
| 2594598 | 11 SEAL-O-RING | 1 | |
| 4P5218 | 12 COVER | 1 | |
| 5D3954 | 13 STUD-TAPERLOCK (5/8-11X4.4-IN) | 2 | |
| 4K0367 | 14 NUT-FULL (5/8-11-THD) | 2 | |
| 1V6341 | 15 SEAL | 2 | |
| 4P5217 | 16 COVER | 1 | |
| 1A1460 | 17 BOLT (1/2-13X2-IN) | 4 | |
| 2B0947 | 18 BOLT (1/2-13X2.25-IN) | 8 | |
| 8T4122 | 19 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 7X3392 | 20 WASHER-HARD (13.5X22.5X3-MM THK) | 2 |
