System And Components
141-6146 PUMP GP-WATERS/N 5HK1-99999
Group No: 141-6146
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0456 | 1 BOLT (M8X1.25X45-MM) | 3 | |
| 1528002 | 2 REGULATOR-WATER TEMPERATURE | 1 | |
| 1013805 | 3 BOLT (M8X1.25X90-MM) | 3 | |
| 6I0645 | 4 BOLT (M8X1.25X25-MM) | 3 | |
| 1407518 | 6 GASKET-HOUSING | 1 | |
| 6I4374 | 7 BOLT (M8X1.25X60-MM) | 2 | |
| 1407514 | 8 RING | 1 | |
| 1407515 | 9 SEAL-O-RING | 1 | |
| 1407512 | 10 KIT-HOSE (WATER) | 1 | |
| 1278286 | 11 CLAMP-HOSE | 2 | |
| 6I4793 | 12 BOLT (M8X1.25X50-MM) | 1 | |
| 1566011 | 13 PUMP GP-WATER | 1 | |
| 1606214 | 14 HOUSING | 1 | |
| 1407505 | 15 COVER | 1 | |
| 1407506 | 16 GASKET-COVER | 1 | |
| 6I0291 | 17 NUT (M8X1.25-THD) | 2 | |
| 1407504 | 18 GASKET (WATER PUMP) | 1 | |
| 1031074 | 19 STUD | 2 | |
| 1013771 | 20 BOLT (M8X1.25X85-MM) | 1 | |
| 6I0260 | BOLT (M8X1.25X25-MM) | 1 |
