162-2087 TURBOCHARGER GPS/N 7BJ67001-UP

Group No: 162-2087
Part NumberPart NameQty
6I02201 GASKET1
6I02542 BOLT (M8X1.25X30-MM)1
6I02913 NUT (M8X1.25-THD)4
6I05634 NUT (M10X1.5-THD)4
6I05725 BOLT (M8X1.25X20-MM)2
6I10646 SEAL-O-RING2
06769107 WASHER1
06878058 CLAMP-HOSE2
10037529 STUD (M8X1.25X30-MM)4
100484110 BOLT (M6X1X10-MM)1
5D102611 CLAMP-BAND2
101380512 BOLT (M8X1.25X90-MM)4
103106613 CLAMP-HOSE1
103213714 HOSE1
106891615 BOLT (M6X1X16-MM)2
107017516 CONNECTOR2
107017717 HOSE1
111822218 BOLT (M8X1.25X16-MM)4
114259019 CONNECTION1
124381520 BOLT (M8X1.25X16-MM)5
138204321 WASHER1
138206122 ADAPTER1
138206523 GASKET1
141287824 TUBE1
141288225 TUBE1
219761826 TURBOCHARGER GP1
143453427 HOSE1
144619328 BOLT8
144619529 MANIFOLD AS-EXHAUST1
148713229A FERRULE2
147457730 BOLT4
149423631 STUD (M10X1.5X37-MM)4
151587432 SEAL2
156600333 GASKET1
156600434 COVER2
160619935 TUBE AS1
162208836 GASKET2
162208937 HOSE1
166821838 MANIFOLD-INLET1
167690339 TUBE AS-OIL SUPPLY1
067626739A CLIP-TUBE1
169684440 HOSE1
176171041 COOLER AS-ENGINE OIL1
194539042 GASKET-MANIFOLD1
1676920KIT-ACTUATOR MOUNTING1
1676921KIT-TURBOCHARGER1
