Assembly
100%

139-1712 LINES GP-FUELS/N 5SW1-UP

Group No: 139-1712
Part NumberPart NameQty
10325291 HOSE (380CM)
10325291A HOSE (20CM)
10325291B HOSE (380CM)
10325291C HOSE (330CM)
6S86202 CLAMP-HOSE8
5K84513 CLIP (LOOP)4
8T41914 BOLT (M10X1.5X16-MM)7
8T41215 WASHER-HARD (11X21X2.5-MM THK)11
9M84066 CLIP (LOOP)5
8T41337 NUT (M10X1.5-THD)2
7Y81678 GROMMET (50-MM ID)2
10873039 GROMMET1
5I387810 GROMMET (50-MM ID)2
093206311 GROMMET2
111738812 PIPE-FUEL1
144929213 PIPE1
138309714 SEPARATOR GP-WATER1
6V902715 SEAL-O-RING2
8T935716 ADAPTER2
3E409117 ELBOW2
1J967118 SEAL-O-RING2
8T419519 BOLT (M10X1.5X30-MM)2
033784920 PLUG2
032810021 WASHER (0.531X0.718X0.064-IN THK)2
7K118122 STRAP-CABLE1
