System And Components
5I-8250 LAMP GP-FLOOD -BOOMS/N 5SW1-UP
Group No: 5I-8250
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X8488 | 1 NUT-HEX THIN (M12X1.5-THD) | 1 | |
| 8T4223 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 9X3463 | 3 LAMP-HALOGEN (24-VOLT, 70-WATT) | 1 | |
| 6V5210 | 4 SCREW-MACHINE (M4X0.7X10-MM) | 2 | |
| 3B4501 | 5 LOCKWASHER | 2 | |
| 1060001 | 6 LENS AS | 1 | |
| 1060002 | 7 BAND | 1 | |
| 1060003 | 8 RING-RUBBER | 1 | |
| 1060004 | 9 RING-FITTING | 1 | |
| 1060005 | 10 SEAT | 1 | |
| 1450556 | 11 BOLT-FLAT HEAD (M12X1.5X45-MM) | 1 | |
| 7Y5288 | 12 SCREW-PAN HEAD (4X10-MM) | 2 |
