156-4079 PANEL GP-CIRCUIT BREAKERS/N 5SW1-478

Group No: 156-4079

Part Number	Part Name	Qty
1364085	1 BRACKET AS	1
8T4191	2 BOLT (M10X1.5X16-MM)	4
8T4121	3 WASHER-HARD (11X21X2.5-MM THK)	3
1114874	4 COVER	1
1394724	5 CIRCUIT BREAKER AS (30-AMPERE)	3
1449129	6 PLATE-CIRCUIT BREAKER	1
6T3645	7 CIRCUIT BREAKER GP (60-AMPERE)	1
3E8320	8 PLATE-INSTRUCTION (BATTERY)	1
7N0718	9 SWITCH GP-DISCONNECT (BATTERY)	1
9X8486	10 SCREW-MACHINE (8-32X0.75-IN)	8
8T0328	11 WASHER-HARD (5.5X10X1-MM THK)	8
1114871	12 RELAY (24-VOLT)	8
7X2619	13 BOLT (M6X1X10-MM)	13
9X8256	14 WASHER (6.6X12X2-MM THK)	35
1059980	15 CLIP	1
8C7581	16 SCREW-MACHINE (M4X0.7X8-MM)	9
0966166	17 WASHER-HARD (4.5X9X1-MM THK)	9
6V9491	18 SCREW-MACHINE (M4X0.7X20-MM)	2
7T4003	19 RESISTOR	1
1059981	20 CLIP	1
1059984	21 CLIP	2
3S2093	22 STRAP-CABLE	4
1564080	23 HARNESS AS	1
1114718	24 CLIP	1
3E5165	25 CAP AS-PROTECTION	1
1343351	26 BRACKET AS	1
8T6411	27 SCREW-MACHINE (M6X1X12-MM)	18
1321863	28 STRIP	1
6V9326	29 SCREW-MACHINE (M2.5X0.45X10-MM)	4
6V8950	30 NUT (M2.5X0.45-THD)	4
1506942	31 WIRE AS	1
1506938	32 WIRE AS	1
1506941	33 WIRE AS	1
7Y5499	34 BLOCK AS-TERMINAL	2
1506934	35 WIRE AS	1
1506935	36 WIRE AS	1
1506937	37 WIRE AS	1
1506943	38 WIRE AS	1
1506939	39 WIRE AS	1
1506940	40 WIRE AS	1
1654026	41 SWITCH AS-MAGNETIC (24-VOLT)(MAIN RELAY)	1
0950742	42 SCREW-MACHINE (M6X1X16-MM)	2
1114870	43 TIMER AS-ON DELAY	1
0950826	44 LOCKWASHER	2
5C8312	45 NUT (M4X0.7-THD)	2
7W1251	46 RESISTOR	1
1251302	47 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY)	1
1495068	48 BAR-BUS	2
1028015	49 RESISTOR AS	1
