System And Components
192-0696 PANEL GP-CIRCUIT BREAKERS/N 5SW579-UP
Group No: 192-0696
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1364085 | 1 BRACKET AS | 1 | |
| 8T4191 | 2 BOLT (M10X1.5X16-MM) | 4 | |
| 8T4121 | 3 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 1114874 | 4 COVER | 1 | |
| 1394724 | 5 CIRCUIT BREAKER AS (30-AMPERE) | 3 | |
| 6V8378 | NUT (10-32-THD) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 8T0328 | WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 1449129 | 6 PLATE-CIRCUIT BREAKER | 1 | |
| 6T3645 | 7 CIRCUIT BREAKER GP (60-AMPERE) | 1 | |
| 6V8378 | NUT (10-32-THD) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 8T0328 | WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 3E8320 | 8 PLATE-INSTRUCTION (BATTERY) | 1 | |
| 7N0718 | 9 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 9X8486 | 10 SCREW-MACHINE (8-32X0.75-IN) | 8 | |
| 8T0328 | 11 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 1114871 | 12 RELAY (24-VOLT) | 8 | |
| 7X2619 | 13 BOLT (M6X1X10-MM) | 13 | |
| 9X8256 | 14 WASHER (6.6X12X2-MM THK) | 35 | |
| 1920697 | 15 HARNESS AS | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 8C7581 | 16 SCREW-MACHINE (M4X0.7X8-MM) | 8 | |
| 0966166 | 17 WASHER-HARD (4.5X9X1-MM THK) | 6 | |
| 1059981 | 20 CLIP | 1 | |
| 1059984 | 21 CLIP | 2 | |
| 3S2093 | 22 STRAP-CABLE | 4 | |
| 1114718 | 24 CLIP | 1 | |
| 3E5165 | 25 CAP AS-PROTECTION | 1 | |
| 1343351 | 26 BRACKET AS | 1 | |
| 8T6411 | 27 SCREW-MACHINE (M6X1X12-MM) | 18 | |
| 1321863 | 28 STRIP | 1 | |
| 6V9326 | 29 SCREW-MACHINE (M2.5X0.45X10-MM) | 4 | |
| 6V8950 | 30 NUT (M2.5X0.45-THD) | 4 | |
| 1506942 | 31 WIRE AS | 1 | |
| 1506938 | 32 WIRE AS | 1 | |
| 1506941 | 33 WIRE AS | 1 | |
| 7Y5499 | 34 BLOCK AS-TERMINAL | 2 | |
| 1506934 | 35 WIRE AS | 1 | |
| 1506935 | 36 WIRE AS | 1 | |
| 1506937 | 37 WIRE AS | 1 | |
| 1506943 | 38 WIRE AS | 1 | |
| 1506939 | 39 WIRE AS | 1 | |
| 1506940 | 40 WIRE AS | 1 | |
| 1654026 | 41 SWITCH AS-MAGNETIC (24-VOLT) | 1 | |
| 4F2294 | NUT-JAM (5/16-24-THD) | 2 | |
| 6V8186 | NUT-FULL (5/16-24-THD) | 2 | |
| 6V8378 | NUT (10-32-THD) | 2 | |
| 0950742 | 42 SCREW-MACHINE (M6X1X16-MM) | 2 | |
| 1114870 | 43 TIMER AS-ON DELAY | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1160128 | SEAL | 1 | |
| 1211038 | HOUSING-RECEPTACLE | 1 | |
| 1211039 | TERMINAL (MALE) | 2 | |
| 0950826 | 44 LOCKWASHER | 2 | |
| 5C8312 | 45 NUT (M4X0.7-THD) | 2 | |
| 7W1251 | 46 RESISTOR | 1 | |
| 1251302 | 47 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY) | 1 | |
| 1495068 | 48 BAR-BUS | 2 | |
| 1028015 | 49 RESISTOR AS | 1 |
