System And Components
121-9102 BOX GP-STORAGES/N 5SW1-UP
Group No: 121-9102
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1219107 | 1 BODY AS | 1 | |
| 1168428 | 2 COVER AS | 1 | |
| 1168438 | 3 SHEET | 1 | |
| 4I2187 | 4 SUPPORT AS | 1 | |
| 7Y3281 | 5 GROMMET | 2 | |
| 8T4133 | 6 NUT (M10X1.5-THD) | 4 | |
| 5P1075 | 7 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 7Y6190 | 8 BOLT (M8X1.25X20-MM) | 4 | |
| 5C7261 | 9 NUT (M8X1.25-THD) | 4 | |
| 8T4224 | 10 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 0963780 | 11 PIN-CLEVIS | 1 | |
| 0950843 | 12 PIN-COTTER | 1 | |
| 8T4136 | 13 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 1219038 | 15 HOOK AS | 1 | |
| 5P3246 | 16 SEAL (1.9M) | ||
| 1224037 | 17 GROMMET | 2 |
