System And Components
150-0724 LINES AR-STICKS/N 5SW1-UP
Group No: 150-0724
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1396001 | 1 HOSE AS | 2 | |
| 6V8398 | 2 SEAL-O-RING | 4 | |
| 1500726 | 3 TUBE AS | 1 | |
| 1500727 | 4 PIPE AS | 1 | |
| 7J9108 | 5 SEAL-O-RING | 6 | |
| 1395995 | 6 TUBE AS | 1 | |
| 1395998 | 7 TUBE AS | 1 | |
| 1508174 | 8 PIPE AS | 2 | |
| 1396003 | 9 BRACKET | 1 | |
| 8T4191 | 10 BOLT (M10X1.5X16-MM) | 6 | |
| 9R1004 | 11 CLIP (TAB) | 8 | |
| 9R1005 | 12 CLIP (SLOT) | 8 | |
| 8T4136 | 13 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 6V8790 | 15 TEE-FACE SEAL | 2 | |
| 1396002 | 16 BRACKET | 2 | |
| 2004102 | 17 CONNECTOR | 4 | |
| 6C6764 | 18 CAP-CONNECTOR | 4 | |
| 1905235 | 19 UNION AS | 4 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1639964 | UNION | 1 | |
| 9S1328 | 20 WASHER (26X41X1.6-MM THK) | 8 | |
| 6V9170 | 21 NUT-BULKHEAD (1-14-THD) | 4 |
