System And Components
150-0725 LINES AR-STICKS/N 5SW1-UP
Group No: 150-0725
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1396001 | 1 HOSE AS | 2 | |
| 6V8398 | 2 SEAL-O-RING | 4 | |
| 1510054 | 3 PIPE AS (LH) | 1 | |
| 7J9108 | 4 SEAL-O-RING | 6 | |
| 1395995 | 5 TUBE AS | 1 | |
| 1395998 | 6 TUBE AS | 1 | |
| 1508174 | 7 PIPE AS | 2 | |
| 1396003 | 8 BRACKET | 1 | |
| 8T4191 | 9 BOLT (M10X1.5X16-MM) | 6 | |
| 9R1004 | 10 CLIP (TAB) | 8 | |
| 9R1005 | 11 CLIP (SLOT) | 8 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 6V8790 | 14 TEE-FACE SEAL | 2 | |
| 1396002 | 15 BRACKET | 2 | |
| 2004102 | 16 CONNECTOR | 4 | |
| 6C6764 | 17 CAP-CONNECTOR | 4 | |
| 1905235 | 18 UNION AS | 4 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1639964 | UNION | 1 | |
| 9S1328 | 19 WASHER (26X41X1.6-MM THK) | 8 | |
| 6V9170 | 20 NUT-BULKHEAD (1-14-THD) | 4 | |
| 1510053 | 22 PIPE AS (RH) | 1 |
