System And Components
147-5304 LINES GP-BOOM CYLINDERS/N 5SW1-UP
Group No: 147-5304
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931292 | 1 CLAMP | 1 | |
| 0965766 | 2 CLAMP | 1 | |
| 1106261 | 3 COUPLING AS | 1 | |
| 1320002 | 4 SUPPORT AS | 1 | |
| 1443614 | 5 SWITCH GP-PRESSURE | 1 | |
| 1510220 | 6 TUBE AS | 1 | |
| 1510221 | 7 TUBE AS | 1 | |
| 1510222 | 8 TUBE AS | 1 | |
| 1510227 | 9 SUPPORT AS | 1 | |
| 1683657 | 10 VALVE GP-LOWERING CONTROL | 1 | |
| 1P3703 | 11 SEAL-RECTANGULAR | 2 | |
| 3D2824 | 12 SEAL-O-RING | 2 | |
| 3J1907 | 13 SEAL-O-RING | 1 | |
| 3K0360 | 14 SEAL-O-RING | 1 | |
| 6V8398 | 15 SEAL-O-RING | 1 | |
| 6V8625 | 16 ELBOW | 1 | |
| 6V8637 | 17 CONNECTOR | 2 | |
| 6V9746 | 18 SEAL-O-RING | 2 | |
| 1053477 | 19 BOLT-SOCKET HEAD (M10X1.5X45-MM) | 4 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 21 NUT (M10X1.5-THD) | 1 | |
| 8T4185 | 22 BOLT (M10X1.5X50-MM) | 4 | |
| 8T4196 | 23 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4198 | 24 BOLT (M10X1.5X100-MM) | 1 | |
| 9S8004 | 25 PLUG (9/16-18-THD) | 1 |
