System And Components
188-6411 LINES GP-BOOM CYLINDER -(RH)S/N 5SW1-UP
Group No: 188-6411
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P3703 | 1 SEAL-RECTANGULAR | 3 | |
| 8T4185 | 2 BOLT (M10X1.5X50-MM) | 8 | |
| 1872654 | 3 TUBE AS | 1 | |
| 1510223 | 4 TUBE AS | 1 | |
| 1320002 | 5 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T4196 | 6 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 1568042 | 8 SUPPORT AS | 1 | |
| 0965766 | 9 CLAMP | 1 | |
| 1863117 | 10 VALVE GP-LOAD CONTROL (BOOM LOWERING, DRIFT REDUCTION) | 1 | |
| 1916772 | KIT-SEAL | ||
| 8T2223 | 11 BOLT-SOCKET HEAD (M10X1.5X45-MM) | 4 | |
| 8T4182 | 12 BOLT (M10X1.5X45-MM) | 1 | |
| 3J1907 | 13 SEAL-O-RING | 4 | |
| 9S8004 | 14 PLUG (9/16-18-THD) | 4 |
