System And Components
171-6574 LINES GP-COUPLERS/N 5SW1-UP
Group No: 171-6574
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T6385 | 1 BOLT (M16X2X180-MM) | 1 | |
| 6V8397 | 2 SEAL-O-RING | 8 | |
| 1396006 | 3 HOSE AS | 2 | |
| 6V8994 | 4 UNION (STRAIGHT) | 4 | |
| 6V9168 | 5 NUT (11/16-16-THD) | 6 | |
| 1665495 | 6 CHANNEL | 1 | |
| 7X2572 | 7 BOLT (M24X3X35-MM) | 2 | |
| 8T4167 | 8 WASHER-HARD (26X44X4-MM THK) | 2 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | 10 BOLT (M10X1.5X25-MM) | 8 | |
| 1396008 | 11 BRACKET | 1 | |
| 1396009 | 12 BRACKET | 1 | |
| 1699727 | 13 BRACKET | 1 | |
| 8T4191 | 14 BOLT (M10X1.5X16-MM) | 2 | |
| 6V8980 | 15 ELBOW | 2 | |
| 0672551 | 16 CLIP | 4 | |
| 8T4132 | 17 NUT (M16X2-THD) | 2 | |
| 1734298 | 18 HOSE AS | 2 | |
| 1439252 | 19 LINK AS | 1 | |
| 1439251 | 20 LINK AS | 1 | |
| 1699724 | 21 HOSE AS | 2 | |
| 6V9829 | 22 CAP (ORFS) | 2 |
