System And Components
147-5315 LINES GP-RETURNS/N 5SW1-UP
Group No: 147-5315
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4192 | 1 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 1179097 | 3 HOSE AS | 2 | |
| 1351146 | 4 TUBE AS | 1 | |
| 8T4195 | 5 BOLT (M10X1.5X30-MM) | 8 | |
| 4J5267 | 6 SEAL-O-RING | 2 | |
| 7I7496 | 7 VALVE GP-CHECK | 1 | |
| 1500736 | 8 TUBE AS | 1 | |
| 1560833 | 9 SUPPORT AS | 1 | |
| 1087178 | PLATE | 1 | |
| 6V8722 | 10 ELBOW | 1 | |
| 7J9108 | 11 SEAL-O-RING | 5 | |
| 3K0360 | 12 SEAL-O-RING | 1 | |
| 1021130 | 13 HOSE AS | 1 | |
| 6V9875 | 14 CONNECTOR | 1 | |
| 5K9090 | 15 SEAL-O-RING | 4 | |
| 2S4078 | 16 SEAL-O-RING | 1 | |
| 6V8637 | 17 CONNECTOR | 2 | |
| 3D2824 | 18 SEAL-O-RING | 5 | |
| 6V9746 | 19 SEAL-O-RING | 2 | |
| 1087602 | 20 HOSE AS | 1 | |
| 6V8713 | 21 CONNECTOR | 2 | |
| 6V9854 | 22 ELBOW (SWIVEL) | 1 | |
| 1566135 | 23 PLATE | 1 | |
| 1566133 | 24 TUBE AS | 1 | |
| 0931293 | 25 CLAMP | 2 | |
| 8T4648 | 26 BOLT (M12X1.75X70-MM) | 2 | |
| 0931296 | 27 CLAMP | 1 | |
| 8T4244 | 29 NUT (M12X1.75-THD) | 1 | |
| 6V8714 | 30 CONNECTOR | 1 |
