System And Components
147-5284 LINES GP-RETURN & FILTERS/N 5SW1-UP
Group No: 147-5284
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4139 | 1 BOLT (M12X1.75X30-MM) | 4 | |
| 8T5436 | 2 BOLT (M10X1.5X130-MM) | 4 | |
| 8T4223 | 3 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 7G5984 | 4 CLIP (TAB) | 1 | |
| 7G5985 | 5 CLIP (SLOT) | 1 | |
| 7G5986 | 6 GROMMET | 1 | |
| 4I8897 | 7 HOSE AS | 1 | |
| 1488327 | 8 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1488355 | 9 ELBOW AS | 2 | |
| 6V9005 | ELBOW | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1421037 | 10 HOSE AS | 1 | |
| 1421040 | 11 HOSE AS | 1 | |
| 1488347 | 12 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 4J0527 | 13 SEAL-O-RING | 1 | |
| 1327551 | 14 SPACER (11X19X6-MM THK) | 4 | |
| 1859063 | 15 VALVE GP-CHECK (SLOW RETURN) | 1 | |
| 8T4956 | 16 BOLT (M12X1.75X35-MM) | 2 | |
| 1510019 | 17 HOSE AS | 1 | |
| 1083819 | 18 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 4 | |
| 1262001 | 19 FLANGE-SPECIAL | 1 | |
| 4J0526 | 20 SEAL-O-RING | 1 | |
| 6V8400 | 21 SEAL-O-RING | 1 | |
| 6J2680 | 22 SEAL-O-RING | 1 | |
| 1600371 | 23 BLOCK | 1 | |
| 7K1181 | 24 STRAP-CABLE | 1 | |
| 1P4578 | 25 FLANGE-HALF | 2 | |
| 4J0522 | 26 SEAL-O-RING | 1 | |
| 8T4195 | 27 BOLT (M10X1.5X30-MM) | 4 | |
| 1P4577 | 28 FLANGE-HALF | 2 | |
| 5H4019 | 29 COVER | 1 | |
| 4J0519 | 30 SEAL-O-RING | 1 | |
| 8T7547 | 31 BOLT (M8X1.25X30-MM) | 4 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4224 | 33 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 1488357 | 34 ELBOW AS | 2 | |
| 6V9008 | ELBOW | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 |
