151-2850 LINES GP-STICKS/N 5SW1-UP

Group No: 151-2850
Part NumberPart NameQty
16654951 CHANNEL1
17259272 HOSE AS1
1P57653 FLANGE-HALF4
7X25724 BOLT (M24X3X35-MM)2
8T41675 WASHER-HARD (26X44X4-MM THK)2
8T41376 BOLT (M10X1.5X20-MM)4
17259267 HOSE AS1
8T41218 WASHER-HARD (11X21X2.5-MM THK)4
18351949 BRACKET1
8U801110 CAP-PROTECTION2
9X627411 WASHER (32.5X50X1.6-MM THK)4
2P129312 LOCKNUT (1-3/16-12-THD)2
183519513 BRACKET1
8T418214 BOLT (M10X1.5X45-MM)8
1P370215 SEAL-RECTANGULAR2
8T638516 BOLT (M16X2X180-MM)1
8T413217 NUT (M16X2-THD)2
231916418 FITTING GP-HYDRAULIC (QUICK DISCONNECT, MALE)2
2393483KIT-REPAIR (QUICK DISCONNECT)1
200410519 CONNECTOR-SPECIAL2
4J052420 SEAL-O-RING2
