System And Components
184-6330 LINES GP-STICK CYLINDERS/N 5SW1-UP
Group No: 184-6330
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1846331 | 1 TUBE AS | 1 | |
| 1053483 | 2 BOLT-SOCKET HEAD (M10X1.5X70-MM) | 4 | |
| 3D2824 | 3 SEAL-O-RING | 1 | |
| 1846333 | 4 TUBE AS | 1 | |
| 1865058 | 5 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 0931292 | 6 CLAMP | 1 | |
| 3J1907 | 7 SEAL-O-RING | 2 | |
| 4J5267 | 8 SEAL-O-RING | 1 | |
| 8T6876 | 9 ELBOW | 2 | |
| 1846332 | 10 TUBE AS | 1 | |
| 6V8398 | 11 SEAL-O-RING | 2 | |
| 1845202 | 12 VALVE GP-LOAD CONTROL | 1 | |
| 1916772 | KIT-SEAL | 1 | |
| 8T4195 | 13 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 1319935 | 15 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T4185 | 16 BOLT (M10X1.5X50-MM) | 5 | |
| 0931294 | 17 CLAMP | 1 | |
| 4I9534 | 18 BAND-MARKER (BROWN) | 1 | |
| 8T4196 | 19 BOLT (M10X1.5X35-MM) | 2 |
