System And Components
203-9959 LINES GP-STICK CYLINDERS/N 5SW1-UP
Group No: 203-9959
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I1676 | 1 CLIP | 2 | |
| 1319935 | 2 SUPPORT AS | 1 | |
| 2039960 | 3 TUBE AS | 1 | |
| 2039961 | 4 TUBE AS | 1 | |
| 2039962 | 5 SUPPORT AS | 1 | |
| 1P3703 | 6 SEAL-RECTANGULAR | 2 | |
| 8T1895 | 7 CLIP (SLOT) | 1 | |
| 8T1896 | 8 CLIP (TAB) | 1 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 2 | |
| 8T4137 | 11 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4185 | 12 BOLT (M10X1.5X50-MM) | 4 | |
| 8T4195 | 13 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 14 BOLT (M10X1.5X35-MM) | 2 | |
| 8T5005 | 15 BOLT (M10X1.5X70-MM) | 4 |
