System And Components
155-0160 MOTOR GP-PISTONS/N 5SW1-UP
Group No: 155-0160
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1281937 | 1 VALVE AS-PILOT | 1 | |
| 1469659 | 2 BLOCK GP-HYDRAULIC | 1 | |
| 1281929 | 3 PIN-DOWEL | 1 | |
| 1550212 | 4 HOUSING | 1 | |
| 1550214 | 5 KIT-SEAL | 1 | |
| 1550216 | 6 SHAFT | 1 | |
| 1550219 | 7 SET-BEARING | 1 | |
| 1568132 | SPACER | 1 | |
| 1550292 | 8 SWASHPLATE | 1 | |
| 1550301 | 9 SHELL-CRADLE | 1 | |
| 1550303 | 10 CONTROL-MOTOR | 1 | |
| 8T7525 | SEAL-O-RING | 1 | |
| 0951750 | SEAL-O-RING | 2 | |
| 1550366 | 11 ROTARY AS | 1 | |
| 1582461 | 12 CLAMP | 2 | |
| 1259706 | 13 DOWEL SCREW | 2 | |
| 1582462 | 14 RING-RETAINING | 1 | |
| 1567970 | 15 VALVE GP-TRAVEL COUNTERBALANCE | 1 | |
| 1582460 | 16 BOLT | 4 | |
| 2421148 | 17 KIT-PLUG (PISTON MOTOR) | 1 |
