Assembly
100%

137-3640 PUMP GP-PISTONS/N 5SW1-UP

Group No: 137-3640
Part NumberPart NameQty
5I87491 SHAFT-FRONT1
5I87612 COVER-SEAL1
09517183 SEAL-O-RING2
09508824 PIN-SPRING4
09512095 NUT (M16X2-THD)4
5I87606 SUPPORT2
09517837 RING-BACKUP2
09515848 SEAL-O-RING2
5I87669 PISTON-SERVO2
095169810 SEAL-O-RING2
5I877011 RING-BACKUP2
5I876712 STOP2
095157513 SEAL-O-RING18
095171714 SEAL-O-RING2
5I877215 EYEBOLT2
5I877416 SETSCREW (M16X2X39-MM)2
5I877817 PISTON AS2
5I878218 PIN AS2
5I876819 STOP2
5I877320 SETSCREW (M16X2X30-MM)2
5I875021 SHAFT-REAR1
5I876222 COVER1
5I881823 BEARING-ROLLER2
8T026924 BOLT-SOCKET HEAD (M6X1X20-MM)4
8T675925 PLUG-PIPE15
5I876326 BODY-CASING2
129797627 RETAINER-BALL2
5I876528 STOP1
5I875729 SPRING18
127597630 BARREL AS1
5I881631 BEARING AS-NEEDLE2
5I875132 COUPLING1
129797533 BLOCK1
096001434 PIN-SPRING2
127597535 BARREL AS1
5I875536 PLATE2
5I875937 PLATE2
5I878138 PLATE AS2
095171139 SEAL-O-RING2
6V568340 BOLT (M6X1X16-MM)4
5I875441 SPACER-BEARING (35X45X3-MM THK)4
6V520042 RING-RETAINING2
5I876943 SEAL-LIP TYPE1
096315044 PLUG3
095158545 SEAL-O-RING4
5I877546 ADAPTER1
102256247 BOLT-SOCKET HEAD (M16X2X180-MM)8
095157448 SEAL-O-RING1
095177749 RING-BACKUP1
5I877150 SEAT1
5H147251 BALL1
