System And Components
131-5914 VALVE GP-PILOTS/N 5SW1-UP
Group No: 131-5914
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0961622 | 1 BUSHING-TERMINAL | 1 | |
| 1315863 | 2 SPRING | 2 | |
| 1184083 | 3 SEAT | 2 | |
| 0951586 | 4 SEAL-O-RING | 4 | |
| 1184086 | 5 ROD | 4 | |
| 1315915 | 6 NUT-SPECIAL | 1 | |
| 4I6365 | 7 JOINT | 1 | |
| 4I6366 | 8 PLATE | 1 | |
| 1184087 | 9 SPRING | 4 | |
| 0940872 | 10 PLATE | 1 | |
| 0996136 | 11 WASHER (5.1X12.5X1-MM THK) | 8 | |
| 1184085 | 12 SEAT | 2 | |
| 1315864 | 13 SPRING | 2 | |
| 0996137 | 14 WASHER (6.1X9X0.2-MM THK) | 4 | |
| 1184082 | 15 SPRING (STANDARD) | 4 | |
| 7I7224 | SPRING (OPTIONAL) | 4 | |
| 1315862 | 16 BODY AS | 1 | |
| 0961621 | 17 SEAL-O-RING | 1 | |
| 0874969 | 18 PLATE | 1 | |
| 7Y0468 | 19 PIN-SPRING | 1 | |
| 0964498 | 20 WASHER-SEALING | 2 | |
| 6V5192 | 21 BOLT-SOCKET HEAD (M8X1.25X30-MM) | 2 | |
| 0961628 | 22 PLUG | 4 | |
| 0940876 | 23 SEAL | 4 | |
| 4I1764 | 24 PLATE | 1 | |
| 5B9304 | 25 SCREW-DRIVE (NO 2X3/16-IN) | 2 | |
| 1211563 | 26 SEAT | 2 | |
| 1211631 | 27 SEAT | 2 | |
| 1347059 | KIT-SPOOL (PILOT VALVE) | 2 | |
| 1347060 | KIT-SPOOL (PILOT VALVE) | 2 |
