System And Components
137-3641 VALVE GP-PUMP CONTROLS/N 5SW1-UP
Group No: 137-3641
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E8025 | 1 BOLT-SOCKET HEAD (M8X1.25X50-MM) | 2 | |
| 5I8787 | 2 LEVER AS | 1 | |
| 5I8815 | 3 PIN | 1 | |
| 5I8789 | 4 PLUG AS | 1 | |
| 5I8814 | 5 RING-RETAINING | 2 | |
| 0951579 | 6 SEAL-O-RING | 2 | |
| 5I8790 | 7 PLUG | 1 | |
| 5I8788 | 8 LEVER AS | 1 | |
| 5I8786 | 9 LEVER AS | 1 | |
| 5I8802 | 10 COVER-PILOT | 1 | |
| 5I8805 | 11 RETAINER | 1 | |
| 5I8820 | 12 SETSCREW (M8X20-MM) | 1 | |
| 5C7261 | 13 NUT (M8X1.25-THD) | 2 | |
| 0951585 | 14 SEAL-O-RING | 1 | |
| 5I8806 | 15 SPRING-PILOT | 1 | |
| 5I8804 | 16 SEAT-SPRING | 1 | |
| 0951709 | 17 SEAL-O-RING | 1 | |
| 5I8803 | 18 PISTON-PILOT | 1 | |
| 0951590 | 19 SEAL-O-RING | 1 | |
| 0951581 | 20 SEAL-O-RING | 1 | |
| 6V8213 | 21 BOLT-SOCKET HEAD (M8X1.25X70-MM) | 2 | |
| 8T0269 | 22 BOLT-SOCKET HEAD (M6X1X20-MM) | 10 | |
| 0962323 | 23 RING-RETAINING (EXTERNAL) | 1 | |
| 8T8442 | 24 BOLT-SOCKET HEAD (M6X1X30-MM) | 2 | |
| 0951578 | 25 SEAL-O-RING | 1 | |
| 0951575 | 26 SEAL-O-RING | 9 | |
| 8T6759 | 27 PLUG-PIPE | 5 | |
| 5I8812 | 28 COVER-BLOCK | 1 | |
| 5I8811 | 29 SPRING | 1 | |
| 0951696 | 30 SEAL-O-RING | 1 | |
| 5I8809 | 31 SEAT-SPRING | 1 | |
| 5I8810 | 32 SPRING-RETURN | 1 | |
| 5I8813 | 33 RING-RETAINING | 1 | |
| 5I8807 | 34 SLEEVE | 1 | |
| 5I8808 | 35 SPOOL | 1 | |
| 1089128 | 36 BODY AS | 1 | |
| 5I8794 | 37 SEAT-SPRING | 1 | |
| 5I8799 | 38 COVER | 1 | |
| 5I8800 | 39 LOCKNUT (M30X1.5-THD) | 1 | |
| 5I8798 | 40 SCREW-ADJUSTMENT | 1 | |
| 5I8821 | 41 SCREW-ADJUSTMENT | 1 | |
| 5I8797 | 42 RETAINER | 1 | |
| 0951584 | 43 SEAL-O-RING | 2 | |
| 0951594 | 44 SEAL-O-RING | 1 | |
| 0951700 | 45 SEAL-O-RING | 1 | |
| 1297972 | 46 SPRING | 1 | |
| 1297971 | 47 SPRING | 1 | |
| 5I8793 | 48 ROD-COMPENSATOR | 1 | |
| 5I8791 | 49 PISTON-COMPENSATOR | 1 | |
| 1297970 | 50 SLEEVE | 1 | |
| 0951586 | 51 SEAL-O-RING | 1 | |
| 1297973 | 52 SLEEVE | 1 | |
| 1297974 | 53 PIN | 1 | |
| 0951573 | 54 SEAL-O-RING | 1 |
