Assembly
100%

147-6688 BOOM GPS/N 5SW1-UP

Group No: 147-6688
Part NumberPart NameQty
14766891 BOOM & BEARING AS1
13728192 BUSHING2
10797343 PIN1
4I33084 PLATE2
8T49565 BOLT (M12X1.75X35-MM)6
8T42236 WASHER-HARD (13.5X25.5X3-MM THK)6
8T47807 BOLT (M20X2.5X30-MM)2
09303498 WASHER (22X60X6-MM THK)2
4I48119 PIN AS1
093008610 SHIM (1-MM THK)2
0930118SHIM (2-MM THK)1
1332424SHIM (0.5-MM THK)1
7X480311 SEAL-LIP TYPE2
3B848912 FITTING-GREASE (1/8-27 PTF)1
107973713 PIN AS1
8T412314 WASHER (22X35X3.5-MM THK)2
118598215 SPACER (73X105X14-MM THK)1
4I330916 SPACER (82X110X3-MM THK)2
093008417 SHIM (1-MM THK)2
0930116SHIM (2-MM THK)1
1132127SHIM (0.5-MM THK)1
093036618 SPACER (93X130X12-MM THK)1
8T675719 PLUG-PIPE1
