Assembly
100%

203-9946 BOOM GPS/N 5SW1-UP

Group No: 203-9946
Part NumberPart NameQty
3B84891 FITTING-GREASE (1/8-27 PTF)1
4I33082 PLATE2
4I33093 SPACER (82X110X3-MM THK)2
4I48114 PIN AS1
09303495 WASHER (22X60X6-MM THK)2
09303666 SPACER (93X130X12-MM THK)2
10797347 PIN1
10797378 PIN AS1
11859829 SPACER (73X105X14-MM THK)1
133286610 PIN AS1
203994711 BOOM & BEARING AS1
1372819BUSHING2
203994912 BOOM & BEARING AS1
1372819BUSHING2
205864213 PIN AS1
205864314 PIN AS1
086029715 WASHER (13X50X6-MM THK)2
086029816 WASHER (19X60X9-MM THK)1
7X480317 SEAL-LIP TYPE2
8T412318 WASHER (22X35X3.5-MM THK)2
8T417919 BOLT (M12X1.75X20-MM)2
8T419020 BOLT (M16X2X25-MM)1
8T422321 WASHER-HARD (13.5X25.5X3-MM THK)6
8T478022 BOLT (M20X2.5X30-MM)2
8T495623 BOLT (M12X1.75X35-MM)6
8T676424 PLUG-PIPE (1/8-27-THD)1
