System And Components
155-1849 LINES GP-AIR CONDITIONERS/N 5SW1-UP
Group No: 155-1849
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1080003 | 1 HOSE AS | 1 | |
| 1125115 | 2 HOSE AS | 1 | |
| 1222739 | 3 HOSE AS | 1 | |
| 1227249 | 4 HOSE AS | 1 | |
| 1088525 | 5 HOSE AS | 1 | |
| 7X0796 | 6 LOCKWASHER (10.2X18.4X2.5-MM THK) | 1 | |
| 8T6466 | 7 BOLT (M10X1.5X60-MM) | 1 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 1P6356 | 9 PLATE | 1 | |
| 1145333 | 10 SWITCH AS-PRESSURE | 1 | |
| 8T4137 | 11 BOLT (M10X1.5X20-MM) | 5 | |
| 6D1641 | 12 CLIP (LOOP) | 5 | |
| 1018789 | 13 ACCUMULATOR-REFRIGERANT | 1 | |
| 6V4356 | 14 CLIP (SLOT) | 1 | |
| 6V4357 | 15 CLIP (TAB) | 1 | |
| 3E4066 | 16 FITTING AS-AIR CONDITIONER | 1 | |
| 1252796 | 17 FITTING AS-AIR CONDITIONER | 1 | |
| 9X7378 | 18 SEAL-O-RING | 1 | |
| 9X7383 | 19 SEAL-O-RING | 2 | |
| 9X7380 | 20 SEAL-O-RING | 3 | |
| 9X7381 | 21 SEAL-O-RING | 3 | |
| 9X7382 | 22 SEAL-O-RING | 2 | |
| 1036100 | 23 FITTING AS-AIR CONDITIONER (QUICK DISCONNECT) | 2 | |
| 3E3535 | 24 DRYER AS-REFRIGERANT (IN-LINE) | 1 | |
| 5P7470 | 25 CLIP (SLOT) | 1 | |
| 5P7471 | 26 CLIP (TAB) | 1 | |
| 8T4195 | 27 BOLT (M10X1.5X30-MM) | 2 | |
| 1071679 | 28 GUARD | ||
| 7Y4528 | 29 GROMMET | 2 | |
| 7Y8165 | 30 GROMMET | 1 | |
| 7K1181 | 31 STRAP-CABLE | 4 |
