System And Components
144-7079 PLATFORM GP-OPERATORS/N 5SW1-UP
Group No: 144-7079
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1217059 | 1 GROMMET | 2 | |
| 1447080 | 2 PLATFORM AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 10 | |
| 1390416 | 3 FLOOR MAT | 1 | |
| 9W6582 | 4 SLEEVE | 4 | |
| 7X3383 | 5 WASHER (22X50X3-MM THK) | 4 | |
| 7Y1537 | 6 LOCKNUT (M20X2.5-THD) | 4 | |
| 9W6584 | 7 WASHER (20.5X114X10-MM THK) | 4 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 7Y9863 | 9 SHIM (0.6-MM THK) | 8 | |
| 7Y9864 | SHIM (1.2-MM THK) | 8 | |
| 0932063 | 10 GROMMET | 1 | |
| 6Y9930 | 11 MOUNT AS | 4 | |
| 7X2532 | 12 BOLT (M20X2.5X130-MM) | 4 | |
| 8T4191 | 13 BOLT (M10X1.5X16-MM) | 4 | |
| 4I3266 | 14 STRIP | 2 |
