System And Components
144-7829 VISOR GP-PROTECTIONS/N 5SW1-UP
Group No: 144-7829
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1456447 | 1 VISOR | 1 | |
| 6C8793 | 2 SUPPORT AS (RH) | 1 | |
| 1408229 | SPACER | 1 | |
| 6C8787 | TUBE | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 6C8795 | 3 SUPPORT AS (LH) | 1 | |
| 1408229 | SPACER | 1 | |
| 6C8787 | TUBE | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 6C8788 | 4 SPACER | 4 | |
| 4I5049 | 5 NUT-SPACER (M6X1-THD) | 6 | |
| 8T2947 | 6 BOLT (M6X1X45-MM) | 4 | |
| 8T4205 | 7 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8T4971 | 8 BOLT (M6X1X30-MM) | 2 | |
| 7X2553 | 9 BOLT (M16X2X40-MM) | 2 | |
| 8T4122 | 10 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 8T4140 | 11 BOLT (M16X2X60-MM) | 2 | |
| 6C8840 | 12 ANGLE (LH) | 1 | |
| 6C8959 | 13 ANGLE (RH) | 1 |
